Features
¡ô Rotating hook:
360¡ãsafe rotated hook, convenient to use.
¡ô Enclosure:
NEMA 12/IP54 powder coated Foundry Cast Aluminum.
¡ô Multi-weighing units:
Kg, lb are selectable, kg are default unit.
¡ô Multi-function operation:
Tare, Zero, Auto zero tracking, Total, Hold, Overload warning and record, operated through infrared remote controller.
¡ô User-friendly design:
Large red 5 digit LED display-digit height 30mm, Battery Operated with low battery indication, Automatic turn off , power-saving function.
¡ô Gravity regulation:
The acceleration of gravity can be regulated through remote controller according to different places value.
¡ô Multi options:
RS-232-continuous or on demand data output, user-selectable. Wireless big screen 3¡å, 5¡å, wireless indicator 180, 280, 380, 580 can match with the scale, user-selectable.
| MODEL |
A(mm) |
B(mm) |
C(mm) |
D(mm) |
H(mm) |
R(mm) |
N.W.(kg) |
| OCS-SX-1 |
95 |
180 |
28 |
264 |
570 |
27 |
12 |
| OCS-SX-2 |
95 |
180 |
28 |
264 |
570 |
27 |
12 |
| OCS-SX-3 |
95 |
180 |
35 |
264 |
580 |
27 |
13 |
| OCS-SX-5 |
124 |
188 |
40 |
264 |
665 |
39 |
21 |
| OCS-SX-10 |
124 |
206 |
48 |
264 |
745 |
45 |
30 |
¡¡
¡¡
| MODEL |
Max. capacity(kg) |
Min. weigh(kg) |
Division(kg) |
Total dispay counts(n) |
| OCS-SX-1 |
1000 |
10 |
0.5 |
2000 |
| OCS-SX-2 |
2000 |
20 |
1 |
2000 |
| OCS-SX-3 |
3000 |
20 |
1 |
3000 |
| OCS-SX-5 |
5000 |
40 |
2 |
2500 |
| OCS-SX-10 |
10000 |
100 |
5 |
2000 |
